iSMA-B-AAC20

The iSMA-B-AAC20 is an advanced control device to building automation and HVAC systems. Using SVM (Sedona Virtual Machine) allows the user to quickly and easily program in real time. Large number of inputs and outputs allows to integrate with other devices and sensors (AAC20 provides 8xUI, 4xDI, 4/6xAO and 4xDO). Legible, fully programmable LCD, can be used as simple interface to local operation of system. Built-in RS485 can be used to expand number of I/O by connecting MINI or MIX series I/O modules using Modbus ASCII/RTU. In addition, to increase the versatility of the controller, it supports many open communications protocols: BACnet, Modbus, SOX, DALI, M-Bus, 1-Wire or oBIX. The AAC20 is mounted in a housing adapted for DIN rail mounting or directly on a panel. Separate, easy to remove connectors allow quick wiring without removing the entire module.

KEY FEATURES

  • Sedona Framework 1.2 support
  • Real Time Clock (RTC)
  • Configuration via web
  • 2x Fast Ethernet with built-in switch
  • RS485 port (Modbus or BACnet)
  • Built-in Modbus Gateway TCP/IP to RS485
  • DALI Interface: built-in power supply (option)
  • M-Bus Interface: up to 20 devices (option)
  • 1-Wire Interface
  • USB Host Interface
  • Built-in LCD Display (option)
  • Micro SD card slot to log historical data and alarms
  • Fast processor with ARM dual core 204MHz

iSMA-B-AAC20

iSMA-B-AAC20-LCD

RAC18-IP

Room Application Controller

The RAC18-IP is a multifunctional device providing comfort in a single room or a zone in the building. 18 onboard I/O’s with Ethernet and serial port make the controller a versatile system for comfort management, light and blind control, and integration and monitoring. The RAC18-IP controller has a built-in nano EDGE ENGINE – the cutting-edge software that allows for constructing multiple applications and provides a set of libraries and components tailored to create cycle-driven user applications. This solution provides an automatic BACnet exposure and real-time programming.
Maintenance and programming of the device are possible from anywhere in real time with a dedicated, free-of-charge tool. The RAC18-IP ensures an easy replacement process with a system and applications on a removable SD card.

Features

  • Room and zone IP management
  • Openness and reliability
  • Seamless programming and maintenance
  • Built-in nano EDGE ENGINE
  • Cycle-driven multithreaded application
  • Favorable licensing system
  • Reference linking method
  • Clear and logical structure
  • 150 Data Points
  • System and applications on SD card
  • 2 fail-safe Ethernet ports with a built-in switch
  • Native BACnet IP
  • Modbus RTU
  • Built-in real-time clock (RTC)
  • Support for over 20 types of temperature sensors
  • Digital inputs with fast pulse counter
  • Triac outputs for thermal actuators
